Resin-rich
COGEBI offers a resin-rich insulation system for the stator windings of rotating machines operating in thermal class 155. These tapes and foils are unique and effective, possess outstanding quality and comply with the relevant IEC 371 standards. Important manufacturers of electrical rotating machines use these tapes and foils throughout the world. RELANEX, RELASTIK and REMIKAFLEX are resin-rich tapes and foils based on calcined or un-calcined muscovite mica paper and REMIKA® with glass-fabric or polyester-film backings. These products enable customers to construct the slot-section and overhang insulation of high-voltage windings that exceed all present standards and requirements.
COGEBI Products:
| Reference | Mica content | Remark |
| Relanex 45.031, 45.033, 45.038 | 76-180 | Main insulation with glass fabric and epoxy novolac |
| Relastik 45.007, 45.036, 45.036R | 150 | Main insulation with PET film carrier and epoxy novolac |
| Remikaflex 45.005, 45.021, 45.022 | 75-110 | Overhang insulation |
